| Type | XJ-65 | XJ-115B | XJ-120 | XJ-150 | XJ-200 |
| Forms of screw andscrew thread |
Double-head equaldepth convergent type |
Double-head convergent type | Double-head convergent type | Double head unequal-depth | Double-head convergent type |
| Screw diameter(mm) | 65 | 115 | 120 | 150 | 200 |
| Length-diameter ratioof screw(L/D | 4 | 4.8 | 4.6 | 4.43 | 4.35 |
| Compression ratio |
|
1.3 |
|
1.34 |
|
| Rotary speed of screw(r/min) | 5.2-52 | 5.4-54 | 5.6-55.6 | 20-26 | 22.4-67.2 |
| Motor power(kw) |
Electromagnetic speed 7.5kw |
Electromagnetic speed 22kw | Electromagnetic speed 22kw |
Frequency control 55kw/ motor commutator18.3-55kw |
motor commutator 25-75kw |
| Production capacity(kg | 50-80 | 100-420 | 100-450 | 700-1200 | 1500-2200 |
| Steam pressure | 0.2-0.3 | 0.4-0.6 | 0.2-0.4 | 0.6 | 0.6-0.8 |
| Cooling water pressure | 0.2-0.3 | 0.2-0.3 | 0.2-0.4 | 0.2-0.3 | 0.2-0.3 |
| Weight(kg | 1200 | 2600 | 3000 | 5000 | 8000 |
